22 395W relayout landscape Posted on April 30, 2024 00:58:41.
Download PDF File
2024-04-22 e-Stang range test Posted on April 23, 2024 23:26:29.
2024-04-22 e-Stang range test
Only 22.5 miles until red light came on! Regen switch still broken which should add a couple of miles back, but it's accelerating towards uselessness. See "e-Stang range test 2024-04-23.xlsx" for details.
e-Stang range test 2024-04-23 Posted on April 23, 2024 23:21:22.
Download XLSX File
2023-08-16 e-Stang range test Posted on April 23, 2024 21:10:50.
e-Stang battery capacity test
8/11-16/2023
25.7 miles driven; yellow light going on regularly but not stuck on so maybe another 1-2 miles before 2.3V cutoff; WAS REGEN SWITCH BROKEN YET?
61.4 Ah capacity
61% proportion of nameplate
59% proportion of new
14.6 years driven on this 2nd Valence pack (replaced under warranty after 2.4 years)
17.8 years estimated life to 50% of nameplate if linear decay
3.2 years left before 50% of nameplate
Nov '26 estimated replacement date at 50% nameplate
63.3 Ah discharged
1.8 Ah charged via regen
3% capacity extended by regen (but clutch switch is currently broken so limited to 12 amps instead of 50 reprogrammed up from 30 which showed 7% increase in range earlier - need to redo this, may be as high as 12% or 28 mile range)
8758 Wh net capacity
57% proportion of nameplate (worse than Ah due to increase in internal resistance)
9040 Wh discharged
2.84 miles per kWh, similar to Mach-e but far less peppy and less cargo
22 395W relayout portrait Posted on April 22, 2024 09:08:01.
Download PDF File
Winter solar panel shade analysis 20220113 Posted on March 12, 2024 11:57:35.
Download PDF File
solar payback calculation Posted on March 11, 2024 13:20:51.
Download PDF File
solar payback v1 b2 Posted on March 11, 2024 00:04:05.
Download XLSX File
Home Power Draw Posted on January 18, 2024 22:28:32.
Download PDF File
California camping ideas Posted on January 15, 2024 21:15:04.
Download XLSX File
